High-Quality Sensors
Utilizes advanced electrochemical sensors for accurate CO detection and early warning.
Wide Detection Range
Detects CO concentration levels ranging from low to dangerous thresholds, ensuring timely alerts.
User-Friendly Design
Simple installation with easy-to-use features like volume control and test/silence buttons.
Reliable Performance
The alarm operates within a wide range of temperatures (-10°C ~ 55°C) and humidity conditions.
Compact & Durable
Small, lightweight design with a 3-year maximum lifespan, making it both efficient and cost-effective.
| Technical Parameter | Value |
| Product Name | Carbon Monoxide Alarm |
| Model | Y100A-AA |
| CO Alarm Response Time | >50 PPM: 60-90 minutes, >100 PPM: 10-40 minutes, >300 PPM: 3 minutes |
| Supply Voltage | DC3.0V (1.5V AA Battery *2PCS) |
| Battery Capacity | About 2900mAh |
| Battery Voltage | ≤2.6V |
| Standby Current | ≤20uA |
| Alarm Current | ≤50mA |
| Standard | EN50291-1:2018 |
| Gas Detected | Carbon Monoxide (CO) |
| Operating Temperature | -10°C ~ 55°C |
| Relative Humidity | ≤95% No Condensing |
| Atmospheric Pressure | 86kPa-106kPa (Indoor use type) |
| Sampling Method | Natural Diffusion |
| Alarm Volume | ≥85dB (3m) |
| Sensors | Electrochemical Sensor |
| Max Lifetime | 3 years |
| Weight | ≤145g |
| Size | 868632.5mm |
The integrated high-definition LCD screen provides real-time information on current CO concentration, ambient temperature, and device status, allowing users to monitor indoor air quality at a glance. The display automatically adjusts brightness at night, ensuring information remains visible without disrupting sleep. It also records peak values, helping users track potential CO sources and identify potential issues with gas appliances before they become hazardous.
Our carbon monoxide detectors precisely measure and display CO concentrations in the 0-999PPM range. The alarm activates when detecting levels of 50PPM or higher, with response times proportional to concentration levels. Our sophisticated algorithm differentiates between temporary spikes and sustained increases, effectively reducing false alarms while ensuring immediate alerts during genuine dangerous situations.
Our carbon monoxide detectors utilize advanced electrochemical sensor technology that delivers exceptional sensitivity and accuracy. These high-performance sensors can detect CO at very low concentrations, providing earlier warning times for enhanced safety. With a service life of up to 10 years, our sensors ensure long-term stable operation with minimal maintenance requirements, making them ideal for residential and commercial installations.
We are committed to delivering high-quality, customized solutions that meet your exact needs. To ensure our products align with your requirements, please provide the following details:
Let us know the specific technical and functional requirements for the product to ensure it meets your standards.
Describe the intended application or environment in which the product will be used, helping us tailor our solutions for your specific needs.
Share your preference for warranty or defects liability terms, allowing us to offer the most suitable coverage.
Please indicate the desired order quantity, as pricing may vary depending on the volume.
The carbon monoxide detector uses an electrochemical sensor to detect the presence of CO in the air. When the CO concentration reaches a dangerous level, it activates both audible and visual alarms to alert individuals to the threat.
The carbon monoxide detector has a maximum lifespan of 3 years, after which the device needs to be replaced to ensure reliable performance.
Yes, the detector is suitable for various environments, including homes, offices, and industrial spaces. However, it should not be exposed to extreme temperatures or humidity levels beyond the recommended range.
The installation process is simple, and the detector can be mounted on the ceiling or wall. Ensure it is placed in areas where CO is most likely to accumulate, such as near fuel-burning appliances or in enclosed spaces.
If the alarm goes off, immediately evacuate the area and seek fresh air. Contact emergency services to inspect the CO levels, and do not re-enter the space until it has been deemed safe.
